Eyecatcher, DA-Anchor
DA-Anchor M16
Product number: 13500
The hooking eye type DA-Anchor M16 version of Eyecatcher has proven itself in various applications, including Rope Acess. For example, on facade maintenance installations for securing users or for maintenance personnel.
Solid anchor point
EN-795:2012 type A certified
Fall Prevention
Standards
AAK Safety webshop?
Our online store is only available for registered business customers, not for private individuals. Don't have an account yet? Register by clicking on log in at the top of the page!
The hook eye is also present in the nacelle of such facade installations as a fall protection device. The DA-Anchor M16 is suitable for mounting to various (building) structures, such as Concrete elements and Steel constructions.
The strength of the anchorage should be calculated by the installer, assuming a tensile value of 13 kN when used by two persons.
Anchor point DA-Anchor for M16
Suitable for 2-person
Suitable for Rope Access 15kN tested
Long service life due to durable materials
Attachment Concrete - Anchor M16 X 140, Galvanised steel grade 8,8 - Tensile strenth 23,7 kN
Attechment Steel - M16 Bolt/Nut DIN 985
Se instalation manual for details
The strength of the anchorage should be calculated by the installer, assuming a tensile value of 13 kN when used by two persons.
Anchor point DA-Anchor for M16
Suitable for 2-person
Suitable for Rope Access 15kN tested
Long service life due to durable materials
Attachment Concrete - Anchor M16 X 140, Galvanised steel grade 8,8 - Tensile strenth 23,7 kN
Attechment Steel - M16 Bolt/Nut DIN 985
Se instalation manual for details
-
Eyecatcher DA-Anchor user manual.pdfdownload
